SOUND CURB®

Key Benefits

  • Fire-resistant high-density wallboard suitable for ceilings requiring enhanced acoustic performance

  • Ideal for ceiling applications in multifamily residential and commercial projects where meeting noise control building code is required

  • Controls low frequency sound transmission and structurally transmitted sound through floors in multi-story structures

  • Gypsum core is reinforced with glass fibers for added strength, sag resistance and fire-resistance

  • Trusted solution by acoustic engineers and contractors - see it in use at Santa Clara Square

Product Description : Fire Resistant Ceiling Panel with Added STC/IIC Performance

SOUND CURB panels are engineered to reduce sound transmission in ceiling applications. The panel is ideal for multilevel residential or commercial projects where fire resistance is required, and additional mass is desired for improved Sound Transmission Class (STC) and Impact Insulation Class (IIC) performance. The product is especially effective for lower frequencies where sound control has proven difficult. The proprietary, high-density, gypsum core is wrapped with 100% recycled face and backing paper. Additional mineral additives have been integrated into the product’s core to increase its performance during exposure to fire. See it in use at Santa Clara Square.

Product Dimensions

TYPE UL CORE THICKNESS WIDTH LENGTH EDGE WEIGHT
SOUND CURB® Type X PG-13 3/4" 48" 10' Tapered 3.1 lbs/ft2

1Length availability may change; other lengths may be available on a special-order basis. Consult with your local PABCO® representative.

2Represents approximate weight for design and shipping purposes. A more exact weight may be available for your area; consult with your local PABCO® representative.

Technical Data

Composition

Core: Naturally occurring gypsum and proprietary additives


Paper: 100% recycled content paper on front, back and long edges
Manufactured

ASTM C1396
Installation

GA-216 Application and Finishing of Gypsum Panel Products


GA-214 - Levels of Finish for Gypsum Panel Products


ASTM C840 Standard Specification for Application and Finishing of Gypsum Board
Surface Burn

ASTM E84


Flame Spread 15


Smoke Developed 0
Combustibility

ASTM E136


Non-Combustible Gypsum Core
Fire Resistance and Sound Control

The PABCO® Sound Design Guide


Sound Design Tool


GA-600 Fire Resistance and Sound Control Design Manual


Underwriters Laboratories - UL Product iQ® for the latest UL Design Numbers
