QuietRock® EZ-Snap® MR

QuietRock® EZ-Snap® MR

Key Benefits

5/8” mold-resistant, sound damped Type X gypsum panels with patented EZ-SNAP technology making it easy to score and snap like standard gypsum wallboard
For residential and commercial applications where sound control and mold resistance are needed
Achieves high sound attenuation and fire resistance in one panel using less space, material and labor than other acoustic alternatives
Installs and finishes like any paper-faced gypsum panel
All the benefits of QuietRock EZ-SNAP with added mold-resistance
High reliability and outperforms other sound attenuation methods, including multi-layered gypsum panels, resilient channel, and soundboard

Product Description : all the benefits of EZ-SNAP panel
with mold resistance

QuietRock EZ-SNAP Mold Resistant delivers high acoustic performance with improved workability to speed up installation time. Our patented EZ-SNAP technology allows installers to easily score and snap the panel because there is no paper or metal in the center of the panel. The product has all the benefits of our EZ-SNAP panel with added mold-resistance for mold sensitive applications. QuietRock ES and ES MR are the go-to sound control solutions for residential, commercial and institutional construction throughout North America. The panels are UL Certified per required testing for fire-resistance, surface burning characteristics, and non-combustibility (core).

Additional Resources

Product Dimensions

TYPE	UL CORE	THICKNESS	WIDTH	LENGTH	EDGE	WEIGHT
QuietRock® ESMR Type X	QuietRock ES	5/8”	48”	8’, 9', 10’, 12'	Tapered	2.6 lbs/ft²

¹Length availability may change; other lengths may be available on a special-order basis. Consult with your local QuietRock® representative.

²Represents approximate weight for design and shipping purposes. A more exact weight may be available for your area; consult with your local QuietRock® representative.

Technical Data

Composition	Core: Naturally occurring gypsum and proprietary additives, laminated with a proprietary sound damping viscoelastic polymer glue. Paper: 100% recycled paper on front, back and long edges
Manufactured	ASTM C1396 Product Standards: ASTM C1766
Installation	QuietRock® EZ-SNAP Installation Instructions (ES & ES MR) QuietRock® EZ-SNAP Installation Video Gypsum Association GA-214, GA-216 ASTM C 840
Mold Resistance	ASTM D3273 Mold Resistance Rating: 10 (highest rating)
Abuse Resistance	ASTM C1629 Surface Abrasion: Level 2 Soft Body: Level 1 Hard Body: Level 2
Surface Burn	ASTM E84 Class A Flame Spread 15 Smoke Developed 0 CAN/ULC-S102-10 Flame Spread 5 Smoke Developed 0
Combustibility	ASTM E136 Non-Combustible Gypsum Core
Fire Resistance and Sound Control	The PABCO® Sound Design Guide Sound Design Tool GA-600 Fire Resistance and Sound Control Design Manual Underwriters Laboratories - UL Product iQ® CKNX R7094 for the latest UL Design Numbers
