5/8” sound damped gypsum panel with radio frequency (RF) shielding, a key component in our RF System
SCIF application approved – RF shielding tested in accordance with IEEE-STD-299
Same benefits as QR530 plus RF shielding providing a single product application for RF shielding, sound control, fire resistance, and impact resistance
Fully grounded metal to metal connected room without requiring metal or foil underlayment
QuietRock 530RF is a high-performance sound damping gypsum panel that is typically used in the construction of high security environments such as SCIF rooms, government offices, and data centers where radio frequency disturbances can impact security, data, and equipment. Use of the complete QuietRF® System is required to achieve the RF shielding: QuietRock 530RF, QuietSeam RF and RF Tape.
QuietRock 530RF is UL Certified for use on several fire-resistance rated assemblies, provides resistance to impact in high traffic areas, and can provide added shear resistance. The panels install and finish like other paper– faced gypsum board but require a saw to cut.
| TYPE | UL CORE | THICKNESS | WIDTH | LENGTH | EDGE | WEIGHT |
|---|---|---|---|---|---|---|
| QuietRock® 530RF | QR-530 | 5/8" | 48" | 8’, 9’, 10’, 12' | Tapered | 2.9 lbs/ft2 |
1Length availability may change; other lengths may be available on a special-order basis. Consult with your local QuietRock® representative.
2Represents approximate weight for design and shipping purposes. A more exact weight may be available for your area; consult with your local QuietRock® representative.
| Composition | Core: A sheet of steel laminated between two gypsum panels with a proprietary viscoelastic polymer glue. The gypsum panels are manufactured with naturally occurring gypsum and non-toxic (proprietary) additives. Paper: 100% recycled paper on front, back and long edges |
|---|---|
| Manufactured | ASTM C1396 |
| Installation | QuietRF® Installation Instructions QuietRock 530RF Installation Video GA-216 Application and Finishing of Panel Products GA-214 Recommended Levels of Board Finish ASTM C840 Standard Specification for Application and Finishing of Gypsum Board |
| Shear-rated | ASTM E72 up to 823 lb/ft average ultimate shear load |
| Impact Resistance | ASTM C1629 Soft Body: Level 3 Hard Body: Level 3 |
| Surface Burn | ASTM E84 Class A Flame Spread 10 Smoke Developed 20 |
| Combustibility | ASTM E136 Non-Combustible Gypsum Core |
| Fire Resistance and Sound Control | Underwriters Laboratories - UL Product iQ® CKNX R7094 for the latest UL Design Numbers |
3-Part Specification for all PABCO® Gypsum and QuietRock ® gypsum panel products.
Datasheet describing benefits, product specs, accessories for QuietRock 530 RF.
Safety Data Sheet for QuietRock 500, 510 & 530 Sound Reducing Gypsum Panels.
Submittal document for QuietRock 510, 530 & 545 sound damping gypsum panels.
Hard Body Impact Test Report for QuietRock® ES and QuietRock® 530 sound reducing panels.
Impact Load Test Report for QuietRock® 530 sound reducing panel.
Engineering Evaluation in accordance with IEEE 299-1997 for QR530RF.
Shear Wall Test Report for QuietRock® 530 Sound Reducing Panel.
Soft Body Impact Test Report for QuietRock® ES and QuietRock® 530.
The finishing requirements for walls and ceilings prior to the application of paints and other decorative finishes.
Quick reference guide to the recommended levels of finish for gypsum panel products.
Installation information for QuietRF System: QuietRock® 530RF, QuietSeam® RF, QuietRF Shielding Tape.
