QuietRock® 510

Key Benefits

1/2" sound damped gypsum panel for new or retrofit residential construction
Ideal for remodels and upgrades, easily installs over existing walls, with no demolition required
Continues to reduce noise even when fixtures are installed, such as shelves or cabinets
UL classified and can be used as an additional layer in fire-resistance rated assemblies
Outperforms other residential sound attenuation methods, including multi-layered gypsum panels, fiberboard, and insulation

Product Description : cost effective sound control
for residential applications

1/2″ QuietRock® 510 is a cost-effective sound damping gypsum panel ideal for residential new construction and remodeling applications. Installs and finishes like standard gypsum panels, no special tools required. QuietRock® 510 outperforms other noise control alternatives such as multiple gypsum panels, fiberboard, and insulation. The product is UL classified and can be used as an additional layer in fire resistance rated assemblies.

Additional Resources

Product Dimensions

TYPE	UL CORE	THICKNESS	WIDTH	LENGTH	EDGE	WEIGHT
QuietRock® 510	QR-510	1/2"	48"	8'-12'	Tapered	2.1 lbs/ft²

¹ Length availability may change; other lengths may be available on a special-order basis. Consult with your local QuietRock® representative.

² Represents approximate weight for design and shipping purposes. A more exact weight may be available for your area; consult with your local QuietRock® representative.

Technical Data

Composition	Core: Naturally occurring gypsum and proprietary additives laminated with a sound damping proprietary viscoelastic polymer glue. Paper: 100% recycled paper on front, back and long edges
Manufactured	ASTM C 1396
Installation	QuietRock System Installation Instructions (510, 530, 545) GA-216 Application and Finishing of Gypsum Panel Products GA-214 - Levels of Finish for Gypsum Panel Products ASTM C840 Standard Specification for Application and Finishing of Gypsum Board
Surface Burn ASTM E84	Class A Flame Spread 15 Smoke Developed 0
Combustibility ASTM E136	Non-Combustible Gypsum Core
Fire Resistance and Sound Control	The PABCO® Sound Design Guide Sound Design Tool Underwriters Laboratories - UL Product iQ® CKNX R7094 for the latest UL Design Numbers
