PABCO LITECORE®

Key Benefits

Lightweight drywall for use on residential walls and ceilings
Sag-resistant, with a proprietary noncombustible, dimensionally stable gypsum core
Can be used on both walls and ceilings eliminating the need to source two different products for your project
For interior non-structural, non-fire-resistance rated applications in new or renovation construction
May be formed to a curve with a short radius, and used as a covering material for flat or curved surfaces

Product Description : Lightweight panel for walls and ceilings

LITECORE is an interior sag-resistant gypsum panel with a proprietary noncombustible, dimensionally stable gypsum core formulated to be lighter than regular wallboard. The product is intended for use in non-structural, non-fire-resistance rated wall and ceiling applications where framing is spaced not more than 24 inches on center. This dual-purpose panel can be used on both walls and ceiling eliminating the need to source separate products. Each panel is encased in 100% recycled paper on the face and back. It can be used for both new construction and renovation projects.

Additional Resources

Product Dimensions

TYPE	UL CORE	THICKNESS	WIDTH	LENGTH	EDGE	WEIGHT
PABCO LITECORE®	N/A	1/2"	48"	8'-12'	Tapered	1.4 lbs/ft2
PABCO LITECORE®	N/A	1/2"	54"	12'	Tapered	1.6 lbs/ft2

¹Length availability may change; other lengths may be available on a special-order basis. Consult with your local PABCO® representative.

²Represents approximate weight for design and shipping purposes. A more exact weight may be available for your area; consult with your local PABCO® representative.

Technical Data

Composition	Core: Naturally occurring gypsum and proprietary additives Paper: 100% recycled paper on front, back and long edges
Manufactured	ASTM C1396
Installation and Finishing	GA-216 Application and Finishing of Gypsum Panel Products GA-214 - Levels of Finish for Gypsum Panel Products ASTM C840 Standard Specification for Application and Finishing of Gypsum Board
Surface Burn	ASTM E84 Flame Spread 15 Smoke Developed 0
Combustibility	ASTM E136 Non-Combustible Gypsum Core
Sound Control	The PABCO® Sound Design Guide Sound Design Tool
