MOLD CURB® PLUS

Key Benefits

Provides the most enhanced mold-and-moisture-resistant protection available in gypsum board products
Engineered for use in high humidity areas where enhanced mold and moisture protection is needed on wall and ceiling applications
Comprised of naturally fire-resistant, non-combustible gypsum core encased in 100% recycled face and backing paper also treated for moisture and mold resistance
Achieves a 10 rating, the highest level of performance for mold and moisture resistance per ASTM D3273
Approved for exterior soffits and corridors or breezeways that are protected from direct exposure

Product Description : Interior mold and moisture resistant gypsum board

MOLD CURB Plus panels are manufactured with a special formulated gypsum core and paper facing, which provide enhanced protection against moisture and mold. The panels have been engineered for use in high humidity areas where enhanced mold and moisture protection is needed for both wall and ceiling applications. The panels contain a naturally fire-resistant, non-combustible gypsum core. Available in ½” Regular for residential construction and 5/8” Type X for fire-rated commercial applications.

Additional Resources

Product Dimensions

TYPE	UL CORE	THICKNESS	WIDTH	LENGTH	EDGE	WEIGHT
MOLD CURB® Plus Regular	N/A	1/2"	48"	8'-12'	Tapered	1.7 lbs/ft2
MOLD CURB® Plus Type X	PG-5W	5/8"	48"	8'-12'	Tapered	2.3 lbs/ft2

¹Length availability may change; other lengths may be available on a special-order basis. Consult with your local PABCO® representative.

²Represents approximate weight for design and shipping purposes. A more exact weight may be available for your area; consult with your local PABCO® representative.

Technical Data

Composition	Core: Naturally occurring gypsum and proprietary additives Paper: 100% recycled treated paper on front, back and long edges
Manufactured	ASTM C1396
Installation	GA-216 Application and Finishing of Gypsum Panel Products GA-214 - Levels of Finish for Gypsum Panel Products ASTM C840 Standard Specification for Application and Finishing of Gypsum Board
Installation and Finishing	GA-216 Application and Finishing of Gypsum Panel Products GA-214 - Levels of Finish for Gypsum Panel Products ASTM C840 Standard Specification for Application and Finishing of Gypsum Board
Mold/Mildew Resistance	ASTM D3273 10 (Highest Rating)
Water Absorption	ASTM C473 ≤5% by weight
Humidified Deflection	ASTM C473 1/2” thick panel 10/8” 5/8” thick panel 5/8”
Surface Burn	ASTM E84 Flame Spread 15 Smoke Developed 0
Combustibility	ASTM E136 Non-Combustible Gypsum Core
Fire Resistance and Sound Control	The PABCO® Sound Design Guide Sound Design Tool GA-600 Fire Resistance and Sound Control Design Manual Underwriters Laboratories - UL Product iQ® CKNX R7094 for the latest UL Design Numbers
