Fire resistant gypsum panels for interior walls and ceilings in residential or commercial construction
Composed of a fire-resistant gypsum core, reinforced with glass fibers to provide increased strength and enhanced fire-resistance
Paper facers are manufactured from 100% recycled paper
Available in 3/4” Type X, 5/8” Type X, 5/8” Type C, and 1/2” Super C
Manufactured to meet or exceed ASTM C1396 Standard Specification for Gypsum Board. FLAME CURB products are non-structural gypsum panels intended for interior walls, ceilings, beams, and columns in residential and commercial applications that require a specific fire resistance. FLAME CURB products are UL Certified per required testing for fire resistance, surface burning characteristics, and non-combustibility (core). 5/8” FLAME CURB® Type C and 1/2” FLAME CURB® Super C are enhanced proprietary Type X panels manufactured to provide additional fire resistance.
| TYPE | UL CORE | THICKNESS | WIDTH | LENGTH | EDGE | WEIGHT |
|---|---|---|---|---|---|---|
| Flame Curb Type X | PG-11 | 5/8" | 48" | 8'-12' | Tapered or Round | 2.2 lbs/ft2 |
| PG-11 | 5/8" | 54" | 8'-12' | Tapered | 2.2 lbs/ft2 | |
| Flame Curb Type X | PG-13 | 3/4" | 48" | 12' | Tapered | 3.0 lbs/ft2 |
| Flame Curb Type C | Type C | 5/8" | 48" | 12' | Tapered | 2.4 lbs/ft2 |
| Flame Curb Super C | PG-C | 1/2" | 48" | 12' | Tapered | 2.0 lbs/ft2 |
1Length availability may change; other lengths may be available on a special-order basis. Consult with your local PABCO® representative.
2Represents approximate weight for design and shipping purposes. A more exact weight may be available for your area; consult with your local PABCO® representative.
| Composition | Core: Naturally occurring gypsum and proprietary additives Paper: 100% recycled paper on front, back and long edges |
|---|---|
| Manufactured | ASTM C1396 |
| Installation | GA-216 Application and Finishing of Panel Products GA-214 Recommended Levels of Board Finish ASTM C840 Standard Specification for Application and Finishing of Gypsum Board |
| Surface Burn | ASTM E84 |
| Combustibility | ASTM E136 |
| Fire Resistance and Sound Control | The PABCO® Sound Design Guide |
3-Part Specification for all PABCO® Gypsum and QuietRock ® gypsum panel products.
Safety Data Sheet for all PABCO Gypsum board products.
Submittal document for FLAME CURB® fire resistant gypsum panel.
The finishing requirements for walls and ceilings prior to the application of paints and other decorative finishes.
Quick reference guide to the recommended levels of finish for gypsum panel products.
Industry-wide average cradle-to-gate EPD for 5/8” type X conventional gypsum board.
HPD v2.2 for FLAME CURB Type C.
HPD v2.2 for FLAME CURB Type X.
Disclosure and Optimization–Sourcing of Raw Materials for 5/8″ FLAME CURB Type C.
Disclosure and Optimization–Sourcing of Raw Materials for FLAME CURB® Type X.
VOC Emission Test Certificate for 5/8” FLAME CURB® Type C, which also applies for 1/2” FLAME CURB® Type C, 5/8”…
